Eliminating Dew–Frost Ambiguity in Subzero Hygrometry with FrostLock™

Eliminate ambiguity with FrostLock™ — known condensate state for unambiguous dew-frost precision

FrostLock™ Technology is a proprietary innovation in the RH Systems DUET Chilled Mirror Hygrometer that addresses a classic challenge in chilled mirror hygrometry: reliably distinguishing between dew (liquid water) and frost (solid ice) on the mirror surface when measuring at temperatures below 0°C.

The Core Problem It Solves

In traditional chilled mirror instruments, when the mirror is cooled below freezing:

• Water vapor can condense as supercooled dew (liquid droplets that remain unfrozen below 0°C due to lack of nucleation sites or other factors).
• It can form frost (ice crystals) directly.
• Or, a mixed/ambiguous state can occur where both phases coexist or transition unpredictably.

This ambiguity leads to measurement uncertainty because:

• Dew point and frost point differ significantly below 0°C (frost point is warmer than the equivalent dew point for the same humidity level).
• Dependent calculations like %RH, ppmv, or other humidity parameters can be incorrect if the wrong phase is assumed.

FrostLock eliminates this "mixed or ambiguous condition," ensuring the instrument always operates with a known condensate state — either frost or super-cooled dew — for precise, unambiguous results.

How FrostLock Works

FrostLock uses the DUET's precision engineering combined with advanced measurement algorithms to actively establish and maintain a defined condensate phase on the mirror below 0°C. While exact internal details (e.g., specific control sequences, optical detection enhancements, etc.) are proprietary, the technology guarantees:

• The mirror's condensate layer is forced into a consistent, known state (solid frost or supercooled liquid dew).
• This state is reliably maintained during measurement, preventing random phase shifts or mixed layers.

This results in harmonious dew-frost discrimination, allowing the DUET to provide accurate simultaneous dew point and frost point readings without the traditional guesswork or manual intervention required in older systems.

Key Benefits

• Resolves long-standing industry misconceptions about dew/frost behavior in chilled mirror tech.
• Ensures accurate calculation of all dependent humidity values (%RH, ppm, etc.) across the full range, especially critical in low-humidity or sub-zero applications (e.g., -60°C frost point).
• Contributes to the DUET's overall ±0.1°C frost/dew point accuracy and ±0.05°C reproducibility.
• Enables the instrument's unique "two measurements, one standard" capability — serving as a portable reference for both dew point and frost point in a single device.
• Improves reliability in demanding metrology, calibration, and field environments where ambiguity could compromise traceability or data quality.

In short, FrostLock is what makes the DUET "revolutionary" for technicians needing trustworthy humidity measurements below freezing — it brings clarity and precision to an area that has historically been prone to error in chilled mirror hygrometers.
